MMBT1616 Transistor
MMBT1616-SHU

MMBT1616 Transistor

0,50 €
In Stock
SKU: MMBT1616-SHU
MMBT1616
General purpose application, swit ching application.
codice: 16
 Back to: Transistor

MMBT1616 Transistor

Type Designator: MMBT1616
   Material of Transistor: Si
   Polarity: NPN
   Maximum Collector Power Dissipation (Pc): 0.35 W
   Maximum Collector-Base Voltage |Vcb|: 60 V
   Maximum Collector-Emitter Voltage |Vce|: 50 V
   Maximum Emitter-Base Voltage |Veb|: 6 V
   Maximum Collector Current |Ic max|: 1 A
   Max. Operating Junction Temperature (Tj): 150 °C
   Transition Frequency (ft): 100 MHz
   Collector Capacitance (Cc): 19 pF
   Forward Current Transfer Ratio (hFE), MIN: 135
   Noise Figure, dB: -
   Package: SOT-23

codice: 16

FEATURES
  • Audio frequency power amplifier.
  • Medium speed switching.

APPLICATIONS
  • General purpose application, swit ching application.
